Security Zone Indicator Panel
The Security Zone Indicator Panel Boxes from the Amico Alert-1 series are constructed of 18-gauge steel with a baked white enamel finish, include a security door with lock and key
Security Zone Indicator Panel Boxes shall be an Amico Alert-1 series.
Each recessed security zone indicator panel box shall consist of the following components: A steel box which can house one to seven zone shut-offs with tube extensions, a security door with lock and key. Gauges and one strip of medical gas labels are included.
The security indicator panel box shall be constructed of 18 gauge steel complete with a baked white enamel finish. Affixed to the opposite sides of the box will be two adjustable steel brackets for the purpose of mounting the box to the structural support. The steel brackets shall accommodate various finished wall thicknesses between 3/8" (9.5 mm) and 1 3/16" (30 mm) and shall be field adjustable.
The door shall be constructed of stainless steel and shall be mounted to the back box assembly by standard #6 * 3/8" tapping screws as provided. Access to the zone shutoffs shall be by turning the key to unlock position and swinging the door open. The security door can be closed and relocked only after the shut-off handles have been returned to the open position.
- Zone valve boxes shall be an Amico Alert-1 series.
- The stainless steel door frame assembly shall be constructed of 14 gauge stainless steel and shall be mounted to the back box assembly by standard number 6-32 screws as provided. The door shall be spot-welded to the frame with a stainless steel hinge. Access to the box shall be by means of a lock and key.
