Surgical Lights
The Amico Surgical Luminaires use high quality LED’s that come in 80 and 90 CRI options. The lenses used are Symmetrical / Asymmetrical and designed to reduce glare. By using a one piece sealed housing and smooth doorframe & lens the luminaire is ideal for easy cleaning and infection control. The housing is designed for either flange or grid ceiling installations.
Construction Material
- Housing: 20-gauge CRS, hole-free seam welded construction
- Lenses: Once piece design; asymmetrical/symmetrical; see options for alternate lens
- Finish: White TGIC polyester powder coat. Salt spray test: 1,000 hours
- Optics: Symmetric/asymmetric reflectors diffused for glare free operation
- Drivers: High power factor electronic constant current, <10% THD, >0.97 pf @ 120 V (Class 2)
- Dimensions: 2' x 2' x 4" (fits into a standard ceiling grid layout)
- Voltage: 120 - 277 - 347 V
- Dimming: 0-10, 1-10 and PWM
- Color Quality: 80+ and 90+ CRI available
- Color Temperature: 3500K, 4000K, 5000K
- Estimated Life of LEDs: LM-80 tested LEDs with calculated L70 longevity over 130,000 hrs @ 55°C
- Listings: Luminaire is certified to UL standards by Intertek. Testing Laboratories for wet locations. UL certified IP65 per IEC 60598.
- Conducted emissions controlled as per MIL-STD-461G.
- Warranty: 5 years
2' x 2' (80+CRI)
| Lumens | Watts | Lm/W | ||
|---|---|---|---|---|
| 3,500K / 80+ CRI | Low | 4,979 | 48 | 105 |
| 3,500K / 80+ CRI | Medium | 6,971 | 70 | 100 |
| 3,500K / 80+ CRI | High | 9,053 | 95 | 96 |
| 4,000K / 80+ CRI | Low | 5,133 | 48 | 108 |
| 4,000K / 80+ CRI | Medium | 7,186 | 70 | 103 |
| 4,000K / 80+ CRI | High | 9,333 | 95 | 99 |
| 5,000K / 80+ CRI | Low | 5,287 | 48 | 111 |
| 5,000K / 80+ CRI | Medium | 7,402 | 70 | 106 |
| 5,000K / 80+ CRI | High | 9,613 | 95 | 102 |
2' x 2' (90+CRI)
| Lumens | Watts | Lm/W | ||
|---|---|---|---|---|
| 3,500K / 90+ CRI | Low | 4,077 | 46 | 89 |
| 3,500K / 90+ CRI | Medium | 5,697 | 67 | 85 |
| 3,500K / 90+ CRI | High | 7,695 | 95 | 81 |
| 4,000K / 90+ CRI | Low | 4,207 | 46 | 92 |
| 4,000K / 90+ CRI | Medium | 5,879 | 67 | 87 |
| 4,000K / 90+ CRI | High | 7,932 | 95 | 84 |
| 5,000K / 90+ CRI | Low | 4,430 | 47 | 94 |
| 5,000K / 90+ CRI | Medium | 6,188 | 69 | 90 |
| 5,000K / 90+ CRI | High | 8,171 | 95 | 86 |
