Gauge for Zone Indicator Panel and Isolation Valve

Isolation Valves

General Features

  • Size: 2"
  • Accuracy: +/- 1.5% of full scale. ASME B40.1 Grade B
  • Range: 0-30" Vac (-100 - 0 kPa)
    0 - 100 psi (0 -700 kPa)
    0 - 300 psi (0-2000 kPa)
  • Temperature: Ambient: -13°F to 140°F
  • Media: Max. 140°F
  • Connection: 1/8" Male NPT Center Back
  • Bourdon Tube: Copper alloy
  • Movement: Copper alloy
  • Dial: White plastic with stop pin
  • Pointer: Black aluminum
  • Case: Black steel
  • Window: Snap-in acrylic
